Specifications
Specifications
| Brand | HELLA |
|---|---|
| Model | TE20 |
| Rated Voltage | 12 V |
| Max Current Consumption | 6 A |
| Power Consumption | 72 W per horn |
| Sound Output | 110 ± 3 dB(A) at 2 m |
| Tone Frequency | 400 Hz (low tone) / 500 Hz (high tone) |
| Length | 113 mm |
| Height | 86 ± 1.5 mm |
| Width | 81 ± 2 mm |
| Operating Temperature | -40°C to +75°C |
| Housing Material | ABS |
| Weather Protection | IP65 |
| Lifespan | 100,000 cycles (ECE-R28) |
| Certification | ECE-R28 |
