Specifications
Specifications
| Model | Pioneer GM-D8701 |
|---|---|
| Amplifier Class | Class D |
| Channels | Mono (1-channel) |
| Max Power Output | 600 W x 1 (4Ω) / 1000 W x 1 (2Ω) / 1600 W x 1 (1Ω) |
| Minimum (RMS) Power Output | 300 W x 1 (4Ω) / 500 W x 1 (2Ω) / 800 W x 1 (1Ω) |
| Frequency Response | 10 Hz – 240 Hz |
| Impedance | 1Ω to 8Ω |
| Total Harmonic Distortion | < 0.5% (100 Hz) |
| Signal-to-Noise Ratio | > 100 dB |
| Crossover Type | Variable LPF, 40 Hz – 240 Hz |
| Bass Boost | 0 dB to 18 dB @ 50 Hz, with wired remote |
| Dimensions | 252 mm x 60 mm x 215 mm |
